Designing High-Performance GPU Kernels with TileLang: Tensor-Core GEMM, Fused Softmax, FlashAttention, and Autotuning

import os
import sys
import math
import time
import subprocess
import traceback
def _sh(cmd: str) -> int:
   print(f"$ {cmd}", flush=True)
   return subprocess.run(cmd, shell=True).returncode
def _bootstrap():
   """Install tilelang if missing. Stable wheel first, nightly as a fallback."""
   try:
       import tilelang
       return
   except ImportError:
       pass
   print(">> installing tilelang (this pulls a bundled TVM, ~1-3 min)\n")
   _sh(f"{sys.executable} -m pip install -q tilelang")
   try:
       import tilelang
       return
   except ImportError:
       print(">> stable wheel unusable, trying nightly channel")
       _sh(f"{sys.executable} -m pip install -q tilelang "
           f"-f https://tile-ai.github.io/whl/nightly")
       import tilelang
if os.path.isdir("/usr/local/cuda"):
   os.environ.setdefault("CUDA_HOME", "/usr/local/cuda")
   os.environ["PATH"] = os.environ.get("PATH", "") + ":/usr/local/cuda/bin"
_bootstrap()
import torch
import torch.nn.functional as F
import tilelang
import tilelang.language as T
def banner(title: str):
   print("\n" + "=" * 78)
   print(f"  {title}")
   print("=" * 78, flush=True)
def bench(fn, warmup: int = 10, rep: int = 50) -> float:
   """Median-ish latency in milliseconds, measured with CUDA events."""
   for _ in range(warmup):
       fn()
   torch.cuda.synchronize()
   start, end = torch.cuda.Event(True), torch.cuda.Event(True)
   start.record()
   for _ in range(rep):
       fn()
   end.record()
   torch.cuda.synchronize()
   return start.elapsed_time(end) / rep
def check(actual: torch.Tensor, ref: torch.Tensor, name: str, tol: float = 2e-2) -> bool:
   """Relative-Frobenius-norm check. Far more meaningful than atol for fp16."""
   a, r = actual.float(), ref.float()
   rel = (a - r).norm() / r.norm().clamp_min(1e-12)
   amax = (a - r).abs().max().item()
   ok = bool(rel < tol) and math.isfinite(amax)
   print(f"   [{'PASS' if ok else 'FAIL'}] {name}: rel_err={rel:.3e}  max_abs={amax:.3e}")
   return ok
banner("0. ENVIRONMENT")
assert torch.cuda.is_available(), "No GPU. Runtime -> Change runtime type -> GPU."
DEV = torch.device("cuda")
PROPS = torch.cuda.get_device_properties(0)
CC = torch.cuda.get_device_capability(0)
SM = CC[0] * 10 + CC[1]
print(f"   tilelang   : {getattr(tilelang, '__version__', 'unknown')}")
print(f"   torch      : {torch.__version__}")
print(f"   GPU        : {PROPS.name}  (sm_{SM}, {PROPS.multi_processor_count} SMs, "
     f"{PROPS.total_memory/2**30:.1f} GiB)")
SMEM_CAP = 48 * 1024 if SM < 80 else 96 * 1024
DEFAULT_STAGES = 2 if SM < 80 else 3
print(f"   smem budget: {SMEM_CAP//1024} KB/block, default num_stages={DEFAULT_STAGES}")
print("   note: tilelang caches compiled kernels in ~/.tilelang/cache, so a")
print("         second run of this cell is dramatically faster.")
@tilelang.jit(out_idx=[-1])
def make_vector_add(N: int, block_N: int = 256, dtype: str = "float32"):
   @T.prim_func
   def main(A: T.Tensor((N,), dtype),
            B: T.Tensor((N,), dtype),
            C: T.Tensor((N,), dtype)):
       with T.Kernel(T.ceildiv(N, block_N), threads=256) as bx:
           for i in T.Parallel(block_N):
               C[bx * block_N + i] = A[bx * block_N + i] + B[bx * block_N + i]
   return main
def section_1():
   banner("1. HELLO, TILE — vector add + generated CUDA")
   N = 1 << 22
   add = make_vector_add(N, block_N=256)
   a = torch.randn(N, device=DEV)
   b = torch.randn(N, device=DEV)
   c = add(a, b)
   check(c, a + b, "vector_add")
   ms = bench(lambda: add(a, b))
   gbs = 3 * N * 4 / (ms * 1e-3) / 1e9
   ref_ms = bench(lambda: a + b)
   print(f"   tilelang: {ms*1e3:8.1f} us  ({gbs:6.1f} GB/s)")
   print(f"   torch   : {ref_ms*1e3:8.1f} us   <- both are pure bandwidth, so a tie"
         f" is the correct outcome")
   src = add.get_kernel_source()
   print("\n   --- generated device code (first 32 lines) ---")
   for line in src.splitlines()[:32]:
       print("   " + line)
   print("   ---------------------------------------------")

@tilelang.jit(out_idx=[-1])

def make_matmul(M: int, N: int, K: int,

block_M: int = 128, block_N: int = 128, block_K: int = 32,

num_stages: int = 3, threads: int = 128,

use_swizzle: bool = False,

dtype: str = "float16", accum_dtype: str = "float"):

@T.prim_func

def main(A: T.Tensor((M, K), dtype),

B: T.Tensor((K, N), dtype),

C: T.Tensor((M, N), dtype)):

with T.Kernel(T.ceildiv(N, block_N),

T.ceildiv(M, block_M),

threads=threads) as (bx, by):

A_shared = T.alloc_shared((block_M, block_K), dtype)

B_shared = T.alloc_shared((block_K, block_N), dtype)

C_local = T.alloc_fragment((block_M, block_N), accum_dtype)

if use_swizzle:

T.use_swizzle(panel_size=10, enable=True)

T.clear(C_local)

for ko in T.Pipelined(T.ceildiv(K, block_K), num_stages=num_stages):

T.copy(A[by * block_M, ko * block_K], A_shared)

T.copy(B[ko * block_K, bx * block_N], B_shared)

T.gemm(A_shared, B_shared, C_local)

T.copy(C_local, C[by * block_M, bx * block_N])

return main

def smem_bytes(block_M, block_N, block_K, stages, itemsize=2):

return (block_M * block_K + block_K * block_N) * itemsize * stages

def section_2():

banner("2. MEMORY HIERARCHY — tiled tensor-core GEMM")

M = N = K = 2048

bm, bn, bk, st = 128, 128, 32, DEFAULT_STAGES

while smem_bytes(bm, bn, bk, st) > SMEM_CAP and st > 1:

st -= 1

print(f"   config: {bm}x{bn}x{bk}, num_stages={st}, "

f"smem={smem_bytes(b
