A Coding Implementation to Recover Hidden Malware IOCs with FLARE-FLOSS Beyond Classic Strings Analysis
In this tutorial, we explore how FLARE-FLOSS helps us recover hidden and obfuscated strings from a Windows PE file. We begin by setting up FLOSS and the MinGW-w64 cross-compiler. We synthesize a small malware-like executable that hides strings using multiple techniques, including static strings, stack-built strings, tight strings, and XOR-decoded strings. After that, we compare the limitations of traditional string extraction tools with FLOSS’s deeper static analysis and emulation-based string recovery. Through this process, we learn how analysts can uncover URLs, registry paths, suspicious APIs, and other indicators of compromise that plain string extraction often misses.
Step 1 — Install FLOSS + MinGW-w64
import subprocess, os, sys, json, re, time
from pathlib import Path
def banner(t): print("\n" + "═"*72 + f"\n {t}\n" + "═"*72)
def sh(cmd, quiet=False, check=False):
r = subprocess.run(cmd, shell=True, capture_output=True, text=True)
if not quiet:
if r.stdout: print(r.stdout.rstrip()[:4000])
if r.returncode and r.stderr: print("[stderr]", r.stderr.rstrip()[:1500], file=sys.stderr)
if check and r.returncode: raise RuntimeError(cmd)
return r
banner("STEP 1 — Install FLOSS + MinGW-w64")
sh("pip install -q flare-floss")
sh("apt-get -qq update && apt-get -qq install -y mingw-w64 binutils-mingw-w64", quiet=True)
sh("floss --version 2>&1 | head -3")
Step 2 — Build a synthetic malware-like PE
banner("STEP 2 — Build a synthetic malware-like PE")
WORK = Path("/content/floss_tutorial"); WORK.mkdir(exist_ok=True); os.chdir(WORK)
SECRETS = [
("FAKE_FLAG_DECODED_SECRET", 0x37),
("https://c2-totally-fake.example/beacon", 0x42),
("SOFTWARE\\Microsoft\\Run\\PersistDemo", 0x5A),
("kernel32.dll!VirtualAllocEx", 0x29),
]
def xor_arr(s, k): return ",".join(f"0x{(ord(c)^k)&0xff:02x}" for c in s)
c = [
'#include <stdio.h>',
'__attribute__((noinline)) static void xord(char* b, int n, int k){}',
'int main(void){',
' puts("PLAIN_STATIC_HELLO_FROM_FLOSS_TUTORIAL");',
'',
' volatile char stk[20];',
]
seq = "STACK_BUILT_STRING"
for i, ch in enumerate(seq): c.append(f" stk[{i}]='{ch}';")
c += [f" stk[{len(seq)}]=0;", " puts((char*)stk);", "",
" volatile char tght[]={'T','I','G','H','T','-','S','T','R',0};",
" puts((char*)tght);", ""]
for i,(s,k) in enumerate(SECRETS):
c += [f" char enc{i}[] = {{ {xor_arr(s,k)}, 0x00 }};",
f" xord(enc{i}, {len(s)}, 0x{k:02x});",
f" puts(enc{i});"]
c += [" return 0;", "}"]
(WORK/"sample.c").write_text("\n".join(c))
sh("x86_64-w64-mingw32-gcc -O0 -fno-stack-protector -o sample.exe sample.c -static-libgcc", check=True)
print(f"\n✓ sample.exe built ({(WORK/'sample.exe').stat().st_size:,} bytes)")
sh("file sample.exe")
Step 3 — Classic `strings` baseline (what gets MISSED)
banner("STEP 3 — Classic `strings` baseline (what gets MISSED)")
classic = set(subprocess.run("strings -a -n 6 sample.exe", shell=True,
capture_output=True, text=True).stdout.splitlines())
print(f"`strings` extracted {len(classic):,} candidates total.")
print("Coverage of our planted secrets in plain `strings`:")
planted = ["PLAIN_STATIC_HELLO_FROM_FLOSS_TUTORIAL", "STACK_BUILT_STRING", "TIGHT-STR"] + [s for s,_ in SECRETS]
for s in planted:
hit = any(s in line for line in classic)
print(f" {'✓ FOUND ' if hit else '✗ MISSED'} {s}")
Step 4 — Run FLOSS (vivisect static + emulation; ~30–90 s)
banner("STEP 4 — Run FLOSS (vivisect static + emulation; ~30–90 s)")
t0 = time.time()
sh("floss --json sample.exe > floss.json 2> floss.log")
print(f"\n[FLOSS finished in {time.time()-t0:.1f}s]")
print("--- last lines of FLOSS log ---")
sh("tail -15 floss.log")
Step 5 — Parse FLOSS JSON output
banner("STEP 5 — Parse FLOSS JSON output")
with open("floss.json") as f: data = json.load(f)
def extract(key):
out = []
for e in data.get("strings", {}).get(key, []):
if isinstance(e, dict): out.append(e)
else: out.append({"string": e})
return out
static_s, stack_s = extract("static_strings"), extract("stack_strings")
tight_s, decoded_s = extract("tight_strings"), extract("decoded_strings")
buckets = {"static": static_s, "stack": stack_s, "tight": tight_s, "decoded": decoded_s}
print(f" metadata.version : {data.get('metadata', {}).get('version','?')}")
for k,v in buckets.items(): print(f" {k+'_strings':<17}: {len(v):>5}")
print("\nDecoded strings recovered (with decoder routine info):")
for e in decoded_s:
s = e.get("string","")
rtn = e.get("decoding_routine"); addr = e.get("address")
rtn_s = f"0x{rtn:x}" if isinstance(rtn,int) else str(rtn)
addr_s = f"0x{addr:x}" if isinstance(addr,int) else str(addr)
print(f" decoder={rtn_s:<12} at={addr_s:<12} → {s!r}")
print("\nStack / tight strings recovered:")
for e in stack_s + tight_s: print(f" → {e.get('string','')!r}")
Step 6 — IOC hunting in the deobfuscated strings
banner("STEP 6 — IOC hunting in the deobfuscated strings")
PATTERNS = [
("URL", re.compile(r"https?://[^\s\"<>]+")),
("IP", re.compile(r"\b(?:\d{1,3}\.){3}\d{1,3}\b")),
("PE/script", re.compile(r"[A-Za-z0-9_]+\.(?:exe|dll|sys|ps1|bat)\b", re.I)),
("Win32 API", re.compile(r"\b(?:Reg(?:Open|Set|Create|Delete)Key(?:Ex)?A?|VirtualAlloc(?:Ex)?|CreateRemoteThread|WinExec|LoadLibraryA?|GetProcAddress|InternetOpenA?)\b")),
("Registry", re.compile(r"SOFTWARE\\\\?[A-Za-z0-9_\\\\]+", re.I)),
("Base64-like", re.compile(r"\b[A-Za-z0-9+/]{24,}={0,2}\b")),
]
hits = []
for kind, items in buckets.items():
for e in items:
s = e.get("string","")
for label, pat in PATTERNS:
if pat.search(s): hits.append((kind, label, s))
if hits:
print(f"{'BUCKET':<10}{'IOC':<14}STRING")
print("-"*72)
for kind,lbl,s in hits[:40]:
print(f"{kind:<10}{lbl:<14}{s[:80]}")
print(f"\n→ {len(hits)} IOC hits total. Note: most are inside the 'decoded' bucket")
print(" — those would be invisible to plain `strings`!")
else:
print("(no IOC pattern matches)")
Step 7 — Visualize string-type counts and length distribution
import matplotlib.pyplot as plt
fig, (ax1, ax2) = plt.subplots(1, 2, figsize=(13, 4.5))
labels = list(buckets); counts = [len(v) for v in buckets.values()]
bars = ax1.bar(labels, counts, color=["#5fa8d3","#62b6cb","#cae9ff","#ff7b7b"])
ax1.set_title("FLOSS strings by type"); ax1.set_ylabel("count")
for b,n in zip(bars,counts): ax1.text(b.get_x()+b.get_width()/2, n, str(n), ha="center", va="bottom")
for kind, items in buckets.items():
lens = [len(e.get("string","")) for e in items]
if lens: ax2.hist(lens, bins=30, alpha=0.55, label=f"{kind} (n={len(lens)})")
ax2.set_title("String-length distribution"); ax2.set_xlabel("characters")
ax2.set_ylabel("frequency (log)"); ax2.set_yscale("log"); ax2.legend()
plt.tight_layout(); plt.savefig("floss_summary.png", dpi=110); plt.show()
print("\n✓ Tutorial complete.")
print(f" Artifacts: {WORK/'sample.exe'}, {WORK/'floss.json'}, {WORK/'floss_summary.png'}")
“`
