How to Build a Single-Cell RNA-seq Analysis Pipeline with Scanpy for PBMC Clustering, Annotation, and Trajectory Discovery
In this tutorial, we perform an advanced single-cell RNA-seq analysis workflow using Scanpy on the PBMC-3k benchmark dataset. We start by loading the dataset, inspecting its structure, and applying quality control checks to evaluate gene counts, total counts, mitochondrial content, and ribosomal gene signals. We then filter low-quality cells and genes, detect potential doublets with Scrublet, normalize the data, apply log transformation, and identify highly variable genes for downstream analysis. Also, we score cell-cycle phases, regress out unwanted technical variation, scale the data, and reduce dimensionality using PCA, UMAP, and t-SNE. We also cluster cells with the Leiden algorithm, identify marker genes, annotate cell populations using canonical PBMC markers, explore trajectory structure with PAGA and diffusion pseudotime, calculate a custom interferon-response score, and finally save the fully analyzed AnnData object for future use.
!pip install -q scanpy leidenalg python-igraph scrublet
import scanpy as sc
import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
import warnings
warnings.filterwarnings("ignore")
sc.settings.verbosity = 3
sc.settings.set_figure_params(dpi=80, facecolor="white", figsize=(5, 5))
sc.logging.print_header()
adata = sc.datasets.pbmc3k()
adata.var_names_make_unique()
print(adata)
adata.var["mt"] = adata.var_names.str.startswith("MT-")
adata.var["ribo"] = adata.var_names.str.startswith(("RPS", "RPL"))
sc.pp.calculate_qc_metrics(
adata, qc_vars=["mt", "ribo"], percent_top=None, log1p=False, inplace=True
)
sc.pl.violin(adata,
["n_genes_by_counts", "total_counts", "pct_counts_mt"],
jitter=0.4, multi_panel=True,
)
sc.pl.scatter(adata, x="total_counts", y="pct_counts_mt")
sc.pl.scatter(adata, x="total_counts", y="n_genes_by_counts")
We install the required single-cell analysis libraries and import Scanpy, NumPy, Pandas, Matplotlib, and warning controls. We load the PBMC-3k benchmark dataset, make gene names unique, and inspect the AnnData object structure. We then calculate quality control metrics for mitochondrial and ribosomal genes and visualize count-level quality patterns using violin and scatter plots.
sc.pp.filter_cells(adata, min_genes=200)
sc.pp.filter_genes(adata, min_cells=3)
adata = adata[adata.obs.n_genes_by_counts < 2500, :].copy()
adata = adata[adata.obs.pct_counts_mt < 5, :].copy()
sc.pp.scrublet(adata)
print("Predicted doublets:", int(adata.obs["predicted_doublet"].sum()))
adata = adata[~adata.obs["predicted_doublet"], :].copy()
adata.layers["counts"] = adata.X.copy()
sc.pp.normalize_total(adata, target_sum=1e4)
sc.pp.log1p(adata)
sc.pp.highly_variable_genes(adata, min_mean=0.0125, max_mean=3, min_disp=0.5)
sc.pl.highly_variable_genes(adata)
adata.raw = adata
adata = adata[:, adata.var.highly_variable].copy()
We filter out low-quality cells and rarely detected genes to improve the reliability of the dataset. We use Scrublet through Scanpy to identify predicted doublets and remove them before deeper analysis. We then preserve raw counts, normalize expression values, apply log transformation, select highly variable genes, and keep only the most informative features.
s_genes = ["MCM5","PCNA","TYMS","FEN1","MCM2","MCM4","RRM1","UNG","GINS2",
"MCM6","CDCA7","DTL","PRIM1","UHRF1","HELLS","RFC2","NASP",
"RAD51AP1","GMNN","WDR76","SLBP","CCNE2","UBR7","POLD3","MSH2",
"ATAD2","RAD51","RRM2","CDC45","CDC6","EXO1","TIPIN","DSCC1",
"BLM","CASP8AP2","USP1","CLSPN","POLA1","CHAF1B","E2F8"]
g2m_genes = ["HMGB2","CDK1","NUSAP1","UBE2C","BIRC5","TPX2","TOP2A","NDC80",
"CKS2","NUF2","CKS1B","MKI67","TMPO","CENPF","TACC3","SMC4",
"CCNB2","CKAP2L","CKAP2","AURKB","BUB1","KIF11","ANP32E",
"TUBB4B","GTSE1","KIF20B","HJURP","CDCA3","CDC20","TTK",
"CDC25C","KIF2C","RANGAP1","NCAPD2","DLGAP5","CDCA2","CDCA8",
"ECT2","KIF23","HMMR","AURKA","PSRC1","ANLN","LBR","CKAP5",
"CENPE","NEK2","G2E3","CBX5","CENPA"]
s_genes = [g for g in s_genes if g in adata.var_names]
g2m_genes = [g for g in g2m_genes if g in adata.var_names]
sc.tl.score_genes_cell_cycle(adata, s_genes=s_genes, g2m_genes=g2m_genes)
sc.pp.regress_out(adata, ["total_counts", "pct_counts_mt"])
sc.pp.scale(adata, max_value=10)
We define S-phase and G2/M-phase marker genes and retain only those present in the dataset. We score each cell for cell-cycle phase, regress out unwanted variation from total counts and mitochondrial percentage, and scale the data for downstream modeling. We then run PCA, inspect explained variance, construct the neighborhood graph, and generate UMAP and t-SNE embeddings.
sc.tl.leiden(adata, resolution=0.5, flavor="igraph", n_iterations=2, directed=False)
sc.pl.umap(adata, color="leiden", legend_loc="on data", title="Leiden clusters")
sc.pl.tsne(adata, color="leiden", legend_loc="on data", title="t-SNE clusters")sc.tl.rank_genes_groups(adata, "leiden", method="wilcoxon")
sc.pl.rank_genes_groups(adata, n_genes=20, sharey=False)
result = adata.uns["rank_genes_groups"]
groups = result["names"].dtype.names
top_df = pd.DataFrame({g: result["names"][g][:10] for g in groups})
print("\nTop 10 markers per cluster:\n", top_df)
marker_genes = {
"B-cell": ["CD79A", "MS4A1"],
"CD8 T
