An overview of modern LLM compiler stack: writing an interactive and hackable compiler

Hey r/LocalLLaMA,

What it means for makers and artists:

A production ML compiler stack is incredibly complex, with tools like TVM (500K+ lines of C++), PyTorch’s layers such as Dynamo, Inductor, and Triton, and XLA, MLIR, Halide, Mojo. This article aims to demystify the core concepts by building a small ML compiler from scratch in pure Python and raw CUDA.

After a month of work, this three-part series has been completed:

• Part 1: Walks an RMSNorm layer through the upper half of the pipeline: Torch IR (captured as FX graph), Tensor IR (decomposing ops into Elementwise / Reduction / IndexMap), Loop IR (a kernel written as a loop nest fused with other kernels), Tile IR (scheduling onto the GPU), Kernel IR (materializing schedules into hardware primitives), and CUDA (emitting source ready for nvcc).
• Part 2: Explains how a loop nest becomes a GPU schedule. Sixteen mechanical Tile-IR passes to split computations into blocks, map them to threads, stage inputs into shared memory, etc.
• Part 3: Finishes with autotuning using SP-MCTS over the cross-product of rule parameters instead of heuristics.

The entire pipeline is controlled via a single CLI:

1. deplodock compile -c "nn.RMSNorm(2048)(torch.randn(1,32,2048))" --ir tensor|loop|tile|kernel|cuda
2. deplodock run --bench -c "nn.Softmax(dim=-1)(torch.randn(1,28,2048,2048))"
3. deplodock tune -c "nn.RMSNorm(2048)(torch.randn(1,32,2048))" -v
4. Full model compilation with Qwen/Qwen2.5-7B

The three parts are self-contained enough that you can skip ahead if interested in one layer: – IR Hierarchy, From PyTorch to Emitted CUDA, – Tile IR, Scheduling Loops onto a GPU, – Autotuning, A Search Loop Over Tile-IR Rewrites.

Key Takeaways

• This series provides a principled approach to understanding and building an ML compiler from scratch in Python and CUDA.
• The autotuning method using SP-MCTS is novel and effective for improving performance on real hardware.
• The CLI tool allows users to inspect, benchmark, and tune the compilation process easily.

For more details, check out the repository.
